Functional Verification of Dynamically Reconfigurable Fpga-Based Systems

By Lingkan Gong, Oliver Diessel, Lingkan; Diessel Oliver: Gong

Book Overview

This book analyzes the challenges in verifying Dynamically Reconfigurable Systems (DRS) with respect to the user design and the physical implementation of such systems. The authors describe the use of a simulation-only layer to emulate the behavior of target FPGAs and accurately model the characteristic features of reconfiguration. Readers are enabled with this simulation-only layer to maintain verification productivity by abstracting away the physical details of the FPGA fabric. Two implementations of the simulation-only layer are included: Extended Re Channel is a System C library that can be used to check DRS designs at a high level; ReSim is a library to support RTL simulation of a DRS reconfiguring both its logic and state. Through a number of case studies, the authors demonstrate how their approach integrates seamlessly with existing, mainstream DRS design flows and with well-established verification methodologies such as top-down modeling and coverage-driven verification.

• Format: Paperback
• Language: English
• ISBN: 3319380869
• ISBN13: 9783319380865
• Release Date: August 2016
• Publisher: Springer
• Length: 216 Pages
• Weight: 0.75 lbs.
• Dimensions: 0.5" x 6.1" x 9.2"
