Flex-Gear Electrical Power Transmission

By National Aeronautics and Space Administration

This study was conducted to develop an alternative way of transferring electricity across a continuously rotating joint, with little wear and the potential for low electrical noise. The problems with wires, slip rings, electromagnetic couplings, and recently invented roll-rings are discussed. Flex-gears, an improvement of roll-rings, are described. An entire class of flexgear devices is developed. Finally, the preferred flex-gear device is optimized for maximum electrical contact and analyzed for average mechanical power loss and maximum stress. For a device diameter of six inches, the preferred device is predicted to have a total electrical contact area of 0.066 square inches. In the preferred device, a small amount of internal sliding produces a 0.003 inch-pound torque that resists the motion of the device. Vranish, John and Peritt, Jonathan Unspecified Center COUPLERS; ELECTRIC CONNECTORS; ELECTRIC CONTACTS; ELECTRICITY; ELECTROMAGNETIC NOISE; FLEXIBLE BODIES; JOINTS (JUNCTIONS); LOW NOISE; POWER TRANSMISSION; ROBOTICS; ROTATING BODIES; BRUSHES (ELECTRICAL CONTACTS); ELECTROMAGNETIC COUPLING; ROBOT ARMS...

• Format: Paperback
• Language: English
• ISBN: 1731262582
• ISBN13: 9781731262585
• Release Date: January 1
• Publisher: Independently Published
• Length: 136 Pages
• Weight: 0.73 lbs.
• Dimensions: 0.3" x 8.5" x 11.0"
