Fiberoptic Characteristics for Extreme Operating Environments

By: Nasa, National Aeronautics and Space Adm

Fiberoptics could offer several major benefits for cryogenic liquid-fueled rocket engines, including lightning immunity, weight reduction, and the possibility of implementing a number of new measurements for engine condition monitoring. The technical feasibility of using fiberoptics in the severe environments posed by cryogenic liquid-fueled rocket engines was determined. The issues of importance and subsequent requirements for this use of fiberoptics were compiled. These included temperature ranges, moisture embrittlement succeptability, and the ability to withstand extreme shock and vibration levels. Different types of optical fibers were evaluated and several types of optical fibers' ability to withstand use in cryogenic liquid-fueled rocket engines was demonstrated through environmental testing of samples. This testing included: cold-bend testing, moisture embrittlement testing, temperature cycling, temperature extremes testing, vibration testing, and shock testing. Three of five fiber samples withstood the tests to a level proving feasibility, and two of these remained intact in all six of the tests. A fiberoptic bundle was also tested, and completed testing without breakage. Preliminary cabling and harnessing for fiber protection was also demonstrated. According to cable manufacturers, the successful -300 F cold bend, vibration, and shock tests are the first instance of any major fiberoptic cable testing below roughly -55 F. This program has demonstrated the basic technical feasibility of implementing optical fibers on cryogenic liquid-fueled rocket engines, and a development plan is included highlighting requirements and issues for such an implementation. Delcher, R. C. Unspecified Center FEASIBILITY ANALYSIS; FIBER OPTICS; LIQUID PROPELLANT ROCKET ENGINES; TECHNOLOGY ASSESSMENT; BEND TESTS; CRYOGENIC ROCKET PROPELLANTS; LOW TEMPERATURE TESTS; OPTICAL FIBERS; SHOCK TESTS; VIBRATION TESTS...

• Format: Paperback
• Language: English
• ISBN: 1731262094
• ISBN13: 9781731262097
• Release Date: January 1
• Publisher: Independently Published
• Length: 136 Pages
• Weight: 0.73 lbs.
• Dimensions: 0.3" x 8.5" x 11.0"
