Experimental Investigation of Railway Box Bridge

By: Modak, Sarika

This study demonstrates the structural analysis and design of RCC box type bridge using manual approach (i.e. MDM method) and by computational approach (Staad-pro) using IRS - CBC codes. The structural elements (top slab, bottom slab, side wall) were designed to withstand Ultimate Load criteria (maximum bending moment and shear force) due to various loads (Dead Load, Live Load, LL surcharge, DL surcharge) and serviceability criteria (Crack width) and a comparative study of the results obtained from the above two approach has been carried out to validate the correctness of the results. Further, it was also observed that the analysis using manual calculation becomes very tedious and cumbersome and for a complex type of structure, thus it is quite a complex task to perform the analysis manually, so the use of computational method (Staad Pro and excel sheet) becomes the obvious choice for design. The results obtained using MDM method shows a good agreement with the results obtained from computational methods.

• Format: Paperback
• Language: English
• ISBN: 6209473415
• ISBN13: 9786209473418
• Release Date: April 2026
• Publisher: LAP Lambert Academic Publishing
• Length: 56 Pages
• Weight: 0.19 lbs.
• Dimensions: 0.1" x 6.0" x 9.0"
