Enovia V5-6r2018: DMU Navigator and Space Analysis

By Ascent - Center for Technical Knowledge

The ENOVIA V5-6R2018: DMU Navigator and Space Analysis learning guide is an introduction to the DMU workbenches of the ENOVIA suite of products. Digital Mock-Up (DMU) is primarily used as a viewing and analysis tool for 3D CAD data. You will be introduced to the DMU interface by viewing, manipulating and analyzing 3D model geometry. Specific focus is made on the Space Analysis workbench, which provides access to clash, sectioning, and comparison tools. Based on the results of these analyses, you will learn to create annotations directly on the 3D geometry in order to communicate information back to the designers.

Topics CoveredDMU user interfaceModel navigation and visualizationFile managementMeasurement toolsClash analysisSectioningDistance and band analysisCompare productsArc through three points3D annotationsAnnotation viewsImage capturePrinting images

PrerequisitesAccess to the V5-6R2018 version of the software, to ensure compatibility with this guide. Future software updates that are released by Dassault Syst mes may include changes that are not reflected in this guide. The practices and files included with this guide might not be compatible with prior versions (i.e., V5-6R2017).Completion of the CATIA V5-6R2018: Introduction to Modeling or CATIA V5-6R2018: Introduction for Managers & Reviewers course is recommended.

• Format: Paperback
• Language: English
• ISBN: 1951139550
• ISBN13: 9781951139551
• Release Date: December 2019
• Publisher: Ascent, Center for Technical Knowledge
• Length: 428 Pages
• Weight: 1.61 lbs.
• Dimensions: 0.9" x 7.5" x 9.3"
