Enabling Rapid and Robust Structural Analysis During Conceptual Design

By: Nasa, National Aeronautics and Space Adm

This paper describes a multi-year effort to add a structural analysis subprocess to a supersonic aircraft conceptual design process. The desired capabilities include parametric geometry, automatic finite element mesh generation, static and aeroelastic analysis, and structural sizing. The paper discusses implementation details of the new subprocess, captures lessons learned, and suggests future improvements. The subprocess quickly compares concepts and robustly handles large changes in wing or fuselage geometry. The subprocess can rank concepts with regard to their structural feasibility and can identify promising regions of the design space. The automated structural analysis subprocess is deemed robust and rapid enough to be included in multidisciplinary conceptual design and optimization studies. Eldred, Lloyd B. and Padula, Sharon L. and Li, Wu Langley Research Center WBS 475122.02.07.02.02

• Format: Paperback
• Language: English
• ISBN: 1793977216
• ISBN13: 9781793977212
• Release Date: January 1
• Publisher: Independently Published
• Length: 28 Pages
• Weight: 0.20 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
