Electronic device with integrated temperature sensor and manufacturing method thereof: United States Patent 9976914

By: Radhakrishnan, Praveen Kumar

A microfluidic-based sensor, comprising: a semiconductor body, having a first and a second side opposite to one another in a direction; a buried channel, extending within the semiconductor body; a structural layer, of dielectric or insulating material, formed over the first side of the semiconductor body at least partially suspended above the buried channel; and a first thermocouple element, including a first strip, of a first electrical conductive material, and a second strip, of a second electrical conductive material different from the first electrical conductive material, electrically coupled to the first strip. The first thermocouple element is buried in the structural layer and partially extends over the buried channel at a first location. A corresponding manufacturing method is disclosed.

• Format: Paperback
• Language: English
• ISBN: B08QZXWM4M
• ISBN13: 9798583558353
• Release Date: January 1
• Publisher: Independently Published
• Length: 28 Pages
• Weight: 0.20 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
