Dynamic Stability Instrumentation System (Dsis). Volume 3; User Manual

By National Aeronautics and Space Administration

The paper is an operating manual for the Dynamic Stability Instrumentation System in specific NASA Langley wind tunnels. The instrumentation system performs either a synchronous demodulation or a Fast Fourier Transform on dynamic balance strain gage signals, and ultimately computes aerodynamic coefficients. The dynamic balance converts sting motor rotation into pitch or yaw plane or roll axis oscillation, with timing information provided by a shaft encoder. Additional instruments control model attitude and balance temperature and monitor sting vibrations. Other instruments perform self-calibration and diagnostics. Procedures for conducting calibrations and wind-off and wind-on tests are listed. Daniels, Taumi S. and Boyden, Richmond P. and Dress, David A. and Jordan, Thomas L. Langley Research Center...

• Format: Paperback
• Language: English
• ISBN: 1730761240
• ISBN13: 9781730761249
• Release Date: January 1
• Publisher: Independently Published
• Length: 72 Pages
• Weight: 0.42 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
