Display device: United States Patent 9972241

By: Tsuge, Hitoshi

A display device includes: a pixel region in which plural pixels, each including a light emitting element, a capacitor, a drive transistor, and a switch transistor, are arranged in rows and columns; scanning lines; signal lines; and parasitic capacitance which occurs between a source node of the light emitting element of each of the plural pixels and a signal line among the signal lines, wherein when images having different grayscales are displayed in the pixels on adjacent rows which are a 1st-row pixel and a 2nd-row pixel, a difference between a gate-source voltage of the drive transistor of the 1st-row pixel and a gate-source voltage of the drive transistor of the 2nd-row pixel is less than a voltage value of one grayscale, the difference being represented by .DELTA.Vdata.times.Cad/(Cs+Cad+Coled).

• Format: Paperback
• Language: English
• ISBN: B08QZSJDMJ
• ISBN13: 9798583459193
• Release Date: January 1
• Publisher: Independently Published
• Length: 28 Pages
• Weight: 0.20 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
