Determination of Interlaminar Toughness of Im7/977-2 Composites at Temperature Extremes and Different Thicknesses

By National Aeronautics and Space Administration

Composite materials are being used in the aerospace industry as a means of reducing vehicle weight. In particular, polymer matrix composites (PMC) are good candidates due to their high strength-to-weight and high stiffness-to-weight ratios. Future reusable space launch vehicles and space exploration structures will need advanced light weight composites in order to minimize vehicle weight while demonstrating robustness and durability, guaranteeing high factors of safety. In particular, the implementation of composite cryogenic propellant fuel tanks (cryotanks) for future reusable launch vehicles (RLVs) could greatly reduce the vehicle's weight versus identically sized cryotanks constructed of metallic materials. One candidate composite material for future cryotank designs is IM7/977-2, which is a graphite/epoxy system. A successful candidate must demonstrate reasonable structural properties over a wide range of temperatures. Since the matrix material is normally the weak link in the composite, tests that emphasize matrix-dominated behavior need to be conducted. Therefore, the objective of this work is to determine the mode I interlaminar fracture toughness of "unidirectional" 8-ply and 16-ply IM7/977-2 through experimental testing. Tests were performed at -196 degrees Celsius (-320 degrees Fahrenheit), 22 degrees Celsius (72 degrees Fahrenheit), 93 degrees Celsius (200 degrees Fahrenheit) and 160 degrees C (320 degrees Fahrenheit). Low temperature testing was completed while the specimen was submerged in a liquid nitrogen bath. High temperature testing was completed in a temperature-controlled oven.Johnson, W. S. and Pavlick, M. M. and Oliver, M. S.Langley Research CenterCOMPOSITE MATERIALS; CRYOGENICS; POLYMER MATRIX COMPOSITES; GRAPHITE-EPOXY COMPOSITES; TOUGHNESS; STIFFNESS; COMPOSITE PROPELLANTS; WEIGHT REDUCTION; ROBUSTNESS (MATHEMATICS); HIGH TEMPERATURE; LOW TEMPERATURE

• Format: Paperback
• Language: English
• ISBN: 172371982X
• ISBN13: 9781723719820
• Release Date: January 1
• Publisher: Independently Published
• Length: 30 Pages
• Weight: 0.21 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
