Deflection-Based Structural Loads Estimation from the Active Aeroelastic Wing F/A-18 Aircraft

By National Aeronautics and Space Administration

Traditional techniques in structural load measurement entail the correlation of a known load with strain-gage output from the individual components of a structure or machine. The use of strain gages has proved successful and is considered the standard approach for load measurement. However, remotely measuring aerodynamic loads using deflection measurement systems to determine aeroelastic deformation as a substitute to strain gages may yield lower testing costs while improving aircraft performance through reduced instrumentation weight. This technique was examined using a reliable strain and structural deformation measurement system. The objective of this study was to explore the utility of a deflection-based load estimation, using the active aeroelastic wing F/A-18 aircraft. Calibration data from ground tests performed on the aircraft were used to derive left wing-root and wing-fold bending-moment and torque load equations based on strain gages, however, for this study, point deflections were used to derive deflection-based load equations. Comparisons between the strain-gage and deflection-based methods are presented. Flight data from the phase-1 active aeroelastic wing flight program were used to validate the deflection-based load estimation method. Flight validation revealed a strong bending-moment correlation and slightly weaker torque correlation. Development of current techniques, and future studies are discussed.Lizotte, Andrew M. and Lokos, William A.Armstrong Flight Research CenterAEROELASTICITY; DEFLECTION; WINGS; F-18 AIRCRAFT; AERODYNAMIC LOADS; BENDING MOMENTS; FEASIBILITY ANALYSIS; STRAIN GAGES; CIRCUITS; POTENTIOMETERS (INSTRUMENTS); WING ROOTS; ROOT-MEAN-SQUARE ERRORS; GROUND TESTS
