Cutting & Stacking Machine for Jelly Stack Building: Lithium-Ion Prismatic Cell

By Mr Vivek T

The machine consists of electrode cutting section, stacking section and unloading section. The electrode cutting section integrates the function of incoming electrode roll unwinding, cathode electrode V-corner punching, electrode cutting, dimension inspection and defect inspection of both surfaces. NG electrode is discharged while good electrode flows into the stacking section. Here, the good cathode/anode electrode is distributed into three stacking stations. In conjunction with separator unwinding and Z-stacking, the electrode is stacked in to a stack. At the unloading section, after the stack is carried out with U-tape pasting, hi-pot test and QR code tape pasting, it will be unloaded to the stack platform automatically.

• Format: Paperback
• Language: English
• ISBN: B0F7M4Q6FR
• ISBN13: 9798282687415
• Release Date: May 2025
• Publisher: Independently Published
• Length: 110 Pages
• Weight: 0.35 lbs.
• Dimensions: 0.2" x 6.0" x 9.0"
