Creo Parametric 2.0: Sheet Metal Design

By Ascent - Center for Technical Knowledge

This learning guide enables you to use your introductory modeling skills to create sheet metal models, including wall, bends, notches, and form features. On completion of this course, the student will have acquired the skills to confidently manipulate sheet metal geometry, adjust bend developed lengths, and convert solid parts.

Course topics: The sheet metal environmentPrimary and secondary wallsBend reliefCorner reliefRegular unbends, back bends, and cutsNotches and punchesBend featuresUnbending complex geometrySheet metal formsDocumenting a sheet metal partConverting solid partsSheet metal setupInvestigating a sheet metal part

Prerequisites:
It is recommended to complete the following, or have the equivalent Creo Parametric experience: Creo Parametric 2.0: Introduction to Solid Modeling - Part 1Creo Parametric 2.0: Introduction to Solid Modeling - Part 2Creo Parametric: Core Update, Wildfire 4.0 to Creo Parametric 2.0 Please note that this learning guide uses commercial practice files which may not be compatible with the Student Edition of Creo Parametric

• Format: Paperback
• Language: English
• ISBN: 0986369500
• ISBN13: 9780986369506
• Release Date: January 2015
• Publisher: Ascent, Center for Technical Knowledge
• Length: 474 Pages
• Weight: 1.78 lbs.
• Dimensions: 0.9" x 7.5" x 9.3"
