Creo Parametric 2.0: Design Documentation and Detailing

By Ascent - Center for Technical Knowledge

This hands-on learning guide is designed for all draftspersons that document designs using Creo Parametric 2.0. It focuses on learning how to use Creo Parametric 2.0 to communicate design information from your part and assembly models.

Topics include: View creationView manipulationDetailing a drawingDrawing notesTolerancesAssembly drawingsDrawing tables2D sketchingSymbolsDrawing formats and templatesUpdated task-based user Interface (Ribbon style interface)3D Annotations

Prerequisites:
It is recommended to complete the following, or have the equivalent Creo Parametric experience: Creo Parametric 2.0: Introduction to Solid Modeling - Part 1Creo Parametric 2.0: Introduction to Solid Modeling - Part 2Creo Parametric: Core Update, Wildfire 4.0 to Creo Parametric 2.0 Please note that this learning guide uses commercial practice files which may not be compatible with the Student Edition of Creo Parametric

• Format: Paperback
• Language: English
• ISBN: 0978933540
• ISBN13: 9780978933548
• Release Date: January 2015
• Publisher: Ascent, Center for Technical Knowledge
• Length: 638 Pages
• Weight: 2.38 lbs.
• Dimensions: 1.3" x 7.5" x 9.3"
