Control Loading System with Spherical Actuator

By Liu Yinghuang

Control loading system (CLS) is a kind of control force sense equipment which provides pilots with rudder load feedback in flight simulator. Control loading system needs complex mechanical structure and multiple single degree-of-freedom (DOF) motors to achieve multi-DOF motion, which increases the inertia redundant force, thus affecting the output performance of the control loading system. Therefore, the objective of this research is to propose a control loading system based on Halbach array spherical actuator, which can realize multi-DOF motion in a single joint, thus simplifying the mechanical structure of traditional control loading system, reducing the excess inertia force, and providing a favorable basis for improving the accuracy of force sense output.

• Format: Paperback
• Language: English
• ISBN: 9999317529
• ISBN13: 9789999317528
• Release Date: April 2024
• Publisher: Eliva Press
• Length: 162 Pages
• Weight: 0.50 lbs.
• Dimensions: 0.3" x 6.0" x 9.0"
