Connector with sub-housing and uniting portion: United States Patent 9972921

By: Matsui, Hajime

It is aimed to provide a connector capable of dealing with a change in the number of poles without structurally changing a mating connector. Housings (11) for accommodating terminal fittings (12) electrically connectable to tab-like terminals (52) include a main housing (11M) having a locking structure (21) for locking a mating connector (52) and a plurality of types of sub-housings (11S) having different number of poles and selectively unitable with the main housing (11M). The main housing (11M) and the sub-housing (11S) are united by coupling side surfaces to each other. A tab insertion groove (25) into which the tab-like terminal (52) is to be inserted at the time of connection to the mating connector is formed in a coupling part of the united housings (11).

• Format: Paperback
• Language: English
• ISBN: B08QYM3WWG
• ISBN13: 9798583316526
• Release Date: January 1
• Publisher: Independently Published
• Length: 26 Pages
• Weight: 0.19 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
