Computer-Aided Engineering in Deep Drawing of Sheet Blanks

By Valerij Alekseyevich Zharkov

It is the second unique full color book on the most powerful CAD/CAE-system Marc of MSC Software Corporation (USA). Is developed the methodology of 3D-modeling of the technological processes of processing the blanks and obtaining the details after a forming on example of widespread operation in the industry: the deep drawing of axisymmetric and box-shaped details taking into account the hardening, anisotropy and springback of blank at processing. The modeling is based on designing of calculated model only on the basis of own powerful graphic possibilities of system Marc without usage of any additional input files and without a writing of programs.

For the purpose of understanding the mechanism of deep drawing a blank, for the correct development of the project in CAD/CAE-system and the correct analysis of results of modeling the deep drawing in this system, in the beginning of the main chapters is resulted the engineering theory of deep drawing by V. A. Zharkov with analytical dependences and Zharkov's regularities in 160 formulas. And only then is given the exact numerical modeling in CAD/CAE-system. In the final chapter are resulted the Zharkov's theory of sheet stamping.

The book consists of the five sections: drawing the axisymmetric and box-shaped details for 1 operation without holder of blank taking into account the hardening and anisotropy of blank, rawing the axisymmetric details with holder of blank for 1 operation, designing in CAE of drawing the high axisymmetric and box-shaped details with holder of blank for 1 operation, designing in CAE of deep drawing the high box-shaped and axisymmetric details for 2 operations, Zharkov's theory of sheet forming, and the sections consist of 16 chapters.

Following the circumstantial step-by-step instructions in the book, any user, even without special preparation, can quickly create the own project in CAD/CAE-system, and further the user can model, study, research and put into practice the processing of blank, to reduce the design time of processing and the cost price of manufacture of drawn details in automobile, aircraft, electrotechnical, crockery, packing and other industries.

The book is intended for engineers and scientists, working in various industries and also for students and teachers of technical institutes and universities.

• Format: Hardcover
• Language: English
• ISBN: 3031226720
• ISBN13: 9783031226724
• Release Date: August 2023
• Publisher: Springer
• Length: 415 Pages
