Composite Blade Structural Analyzer (Cobstran) User's Manual

By National Aeronautics and Space Administration

The installation and use of a computer code, COBSTRAN (COmposite Blade STRuctrual ANalyzer), developed for the design and analysis of composite turbofan and turboprop blades and also for composite wind turbine blades was described. This code combines composite mechanics and laminate theory with an internal data base of fiber and matrix properties. Inputs to the code are constituent fiber and matrix material properties, factors reflecting the fabrication process, composite geometry and blade geometry. COBSTRAN performs the micromechanics, macromechanics and laminate analyses of these fiber composites. COBSTRAN generates a NASTRAN model with equivalent anisotropic homogeneous material properties. Stress output from NASTRAN is used to calculate individual ply stresses, strains, interply stresses, thru-the-thickness stresses and failure margins. Curved panel structures may be modeled providing the curvature of a cross-section is defined by a single value function. COBSTRAN is written in FORTRAN 77. Aiello, Robert A. Glenn Research Center...

• Format: Paperback
• Language: English
• ISBN: 1730848923
• ISBN13: 9781730848926
• Release Date: January 1
• Publisher: Independently Published
• Length: 86 Pages
• Weight: 0.49 lbs.
• Dimensions: 0.2" x 8.5" x 11.0"
