Cold Flow Testing of a Modified Subscale Model Exhaust System for a Space Based Laser
The aim of this research was a continued study of gas-dynamic phenomena that occurred in a set of stacked nozzles as reported by Captains Ian Bautista in 2003 and Scott Bergren in 2002. The arrangement of the stacked nozzles was a modified version of a 1/5th scale-model of one quadrant of the conceptual Space Based Laser Integrated Flight Experiment (SBL IFX) gas dynamic laser. Rather than cylindrical rings of nozzles, the stacked nozzles were flat and able to be rotated about a vector normal to the nozzle exits. This set of stacked flat nozzles was installed on a blow-down/vacuum wind tunnel, which in addition to the nozzles, consisted of a stilling chamber, centerbody, supersonic diffuser, and transition structure to join the vacuum and test sections. The goals of this research were two fold; first, modify the original scale-model of the stacked cylindrical rings of nozzles so schlieren photography could be used to visualize an average flow field across the nozzles. Secondly, using the schlieren photographs, in conjunction with pressure data, observe the interactions between the individual nozzles. Results have shown that the modified nozzle array produces a vastly complex flow field as well as a highly supersonic flow regime, with Mach numbers that reach as high as 5.6.
This work has been selected by scholars as being culturally important, and is part of the knowledge base of civilization as we know it. This work was reproduced from the original artifact, and remains as true to the original work as possible. Therefore, you will see the original copyright references, library stamps (as most of these works have been housed in our most important libraries around the world), and other notations in the work.
This work is in the public domain in the United States of America, and possibly other nations. Within the United States, you may freely copy and distribute this work, as no entity (individual or corporate) has a copyright on the body of the work.
As a reproduction of a historical artifact, this work may contain missing or blurred pages, poor pictures, errant marks, etc. Scholars believe, and we concur, that this work is important enough to be preserved, reproduced, and made generally available to the public. We appreciate your support of the preservation process, and thank you for being an important part of keeping this knowledge alive and relevant.
