Characterizing a Co-Flow Nozzle for Use in a Filtered Rayleigh Scattering System
Research was conducted on the flow field exiting a co-annular flow nozzle for use in filtered Rayleigh scattering flow visualizations. More specifically, the flow visualizations were of the flow field exiting a coflow nozzle and illuminated by a tunable, nominal 4.2 watt narrow line width Argon laser operating at 514.5nm. ND: YAG lasers are typically used in this application, but some of the properties of a tunable Argon laser make it an attractive alternative. Before generating flow visualizations, the coflow nozzle was characterized both experimentally and computationally. Due to a flow asymmetry in the outer annulus flow field, the nozzle was redesigned using a commercially available computational fluid dynamics program (Fluent) to produce a more homogeneous exit plane velocity profile. The redesigned nozzle was built and experimentally tested through the use of a three dimensional traverse controlled Pitot probe resulting in good relationship between the computational and experimental results. The sharp cutoff molecular iodine filters used to reduce the incident frequency light were tested and the locations of their iodine absorption transitions were determined. Finally, the argon laser was used to produce flow visualizations at both 100 Hz and 1 kHz frame rates.
This work has been selected by scholars as being culturally important, and is part of the knowledge base of civilization as we know it. This work was reproduced from the original artifact, and remains as true to the original work as possible. Therefore, you will see the original copyright references, library stamps (as most of these works have been housed in our most important libraries around the world), and other notations in the work.
This work is in the public domain in the United States of America, and possibly other nations. Within the United States, you may freely copy and distribute this work, as no entity (individual or corporate) has a copyright on the body of the work.
As a reproduction of a historical artifact, this work may contain missing or blurred pages, poor pictures, errant marks, etc. Scholars believe, and we concur, that this work is important enough to be preserved, reproduced, and made generally available to the public. We appreciate your support of the preservation process, and thank you for being an important part of keeping this knowledge alive and relevant.
