Cfd Modeling of Turbulent Flows Around the Ssme Main Injector Assembly Using Porosity Formulation

By: Nasa, National Aeronautics and Space Adm

Hot gas turbulent flow distribution around the main injector assembly of the Space Shuttle Main Engine (SSME) and LOX flow distribution through the LOX posts have a great effect on the combustion phenomena inside the main combustion chamber. In order to design a CFD model to be an effective engineering analysis tool with good computational turn-around time (especially for 3-D flow problems) and still maintain good accuracy in describing the flow features, the concept of porosity was employed to describe the effects of blockage and drag force due to the presence of the LOX posts in the turbulent flow field around the main injector assembly of the SSME. Two-dimensional numerical studies were conducted to identify the drag coefficients of the flows, both through tube banks and round the shielded posts, over a wide range of Reynolds numbers. Empirical, analytical expressions of the drag coefficients as a function of local flow Reynolds number were then deduced. The porosity model was applied to the turbulent flow around the main injector assembly of the SSME, and analyses were performed. The 3-D CFD analysis was divided into three parts: LOX dome, hot gas injector assembly, and hydrogen cavity. The numerical results indicate that the mixture ratio at the downstream of injector face was close to stoichiometric around baffle elements. Cheng, Gary C. and Chen, Y. S. and Farmer, Richard C. Unspecified Center...

• Format: Paperback
• Language: English
• ISBN: 1729315631
• ISBN13: 9781729315637
• Release Date: January 1
• Publisher: Independently Published
• Length: 60 Pages
• Weight: 0.36 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
