Building Details [With Dvdrom]

By Frank M. Snyder

Each issue consisted of ten beautifully executed sixteen- by twenty-one-inch drawings showing details of houses, civic buildings, banks, churches, clubs, and other structures designed by some of the period's leading architects, including McKim, Mead & White, John Russell Pope, Grosvenor Atterbury, and Cram, Goodhue & Ferguson. Redrawing from the architects' working drawings, Snyder paid careful attention to scale, materials, and dimensions, and he incorporated full explanatory notes as well as small photographs of the projects within each plate. Intended as a design tool for architects, Building Details gives numerous construction and design suggestions that Snyder urged could be "readily adapted to any Work having similar requirements, using different materials, sizes and proportions than those shown, either for more or less expensive work." In addition to showing the problem worked out, the drawings also would "save much valuable time in preparing Drawings of similar work" and "call attention to many things often overlooked in the preparation of Working Drawings and Specifications." Not only is Building Details important in showing how architects learned and drew from the designs of the great masters; it is a rare and beautiful documentation of how these important early-twentieth-century architects realized their designs. Snyder's 120 plates clarify details that continue to confront architects today and allow us to see thoroughly how the buildings we admire were put together. Building Details is a trove of knowledge that goes beyond conventional printed sources and continues to be an important resource for architects working today. Also included is a DVD-ROM that contains printable TIFF files of all the plates in the original edition of Building Details , at their original size of sixteen by twenty-one inches.

• Format: Hardcover
• Language: English
• ISBN: 0393732452
• ISBN13: 9780393732450
• Release Date: October 2007
• Publisher: W. W. Norton & Company
• Length: 144 Pages
• Weight: 1.35 lbs.
• Dimensions: 0.6" x 10.2" x 13.8"

Customer Reviews

Great Architectural Reprint

This is a reducted size reprint of Frank Synder's 12 part serial BUIDLING DETAILS from 1906 to 1914 which consisted of plates of architectural details redrawn from the leading architects of the day. Each plate, often including at least partial elevations and/or sections, is masterly composed with an occasional thumbnail photo giving additional clarification. The range of projects is great, from schools, churches, banks, and government buildings, to fine homes. Other than identification and limited notes on the plates there is no descriptive text as such, however. The introduction by Pennoyer and Walker only discusses the significance of Synder's original work and others of the same ilk. While these technical drawings would undoubtedly be a valuable reference to architects practicing in the classical mode, they might be too limiting to interest the non-professional.
