Apparatus for Measuring High-Flux Heat Transfer in Radiatively Heated Compact Exchangers

By: Nasa, National Aeronautics and Space Adm

An apparatus is described which can deliver uniform heat flux densities of up to 80 W/sq cm over an area 7.8 cm x 15.2 cm for use in measuring the heat transfer and pressure drop in thin (6 mm or less), compact heat exchangers. Helium gas at flow rates of 0 to 40 kg/h and pressures to 6.9 MPa (1000 psi) is the working fluid. The instrumentation used in the apparatus and the methods for analyzing the data is described. The apparatus will be used initially to test the performance of prototype cooling jackets for the engine struts of the National Aerospace Plane (NASP). Olson, Douglas A. Unspecified Center NASA ORDER L-7400-C...

• Format: Paperback
• Language: English
• ISBN: 172910679X
• ISBN13: 9781729106792
• Release Date: January 1
• Publisher: Independently Published
• Length: 38 Pages
• Weight: 0.25 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
