Antenna Pattern Control Using Impedance Surfaces

By: Nasa, National Aeronautics and Space Adm

A hybrid numerical technique is developed for electrically large pyramidal horn antennas radiating in free space. A stepped-waveguide method is used to analyze the interior surfaces of the horn transition. The Electric Field Integral Equation (EFIE) is employed on the outer surfaces of the pyramidal horn including the radiating aperture. Meanwhile, the Magnetic Field Integral Equation (MFIE) is used on the aperture to relate the aperture fields and those in the horn transition. The resultant hybrid field integral equation (HFIE) is solved numerically by the method of moments. This formulation is both accurate and numerically stable so that high-gain microwave pyramidal horns can be analyzed rigorously. Far-field radiation patterns, both computed and measured, are presented for three electrically-large x-band horn antennas. The comparisons demonstrate that this method is accurate enough to predict the fine pattern structure at wide angles and in the back region. Computed far-field patterns and aperture field distribution of two smaller x-band horns are also presented along with a discussion on the validity of the approximate aperture field distributions routinely used in the analysis and design of pyramidal horns. Balanis, Constantine A. and Liu, Kefeng Unspecified Center NAG1-1183...

• Format: Paperback
• Language: English
• ISBN: 1729176240
• ISBN13: 9781729176245
• Release Date: January 1
• Publisher: Independently Published
• Length: 30 Pages
• Weight: 0.21 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
