Analytical Investigation of the Hygrothermal Effects and Parametric Study of the Edge Crack Torsion (Ect) Mode 3 Test Lay-Ups

By: Nasa, National Aeronautics and Space Adm

A shear deformation theory including residual thermal and moisture effects is developed for the analysis of either symmetric or unsymmetric laminates with mid-plane edge delamination under torsion loading. The theory is based on an assumed displacement field which includes shear deformation. The governing equations and boundary conditions are obtained from the principle of virtual work. The analysis of the (90/(+/- 45)(n)/(-/+ 45)(n)/90)(s) ECT mode 3 test lay-up indicates that there are no hygrothermal effects on the mode 3 strain energy release rate because the laminate, and both sublaminates above and below the delamination, are symmetric lay-ups. A further parametric study reveals that some other lay-ups can have negligible hygrothermal effects even when the sublaminates above and below the delamination are not symmetric about their own mid-planes. However, these lay-ups may suffer from distortion after the curing process. Another Interesting set of lay-ups investigated is a class of antisymmetric laminates with (+/-(theta/(theta -90)(2)/theta))(n) lay-ups. It is observed that when n takes on even numbers (2 and 4), both hygrothermal and mode 1 effects can be neglected. From this point of view, these lay-ups provide a way to determine the mode 3 toughness between two dissimilar layers. However, when n takes on odd numbers (1 and 3), both hygrothermal and mode 1 effects may be strong in these lay-ups. In particular, when theta equals 45 deg, the lay-ups are free from both hygrothermal and mode 1 effects irrespective of n. Li, Jian and Obrien, T. Kevin Langley Research Center RTOP 505-63-50-04...

• Format: Paperback
• Language: English
• ISBN: 1729103782
• ISBN13: 9781729103784
• Release Date: January 1
• Publisher: Independently Published
• Length: 40 Pages
• Weight: 0.26 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
