An In-Depth Probabilistic Study of External Tank Attach Ring

By National Aeronautics and Space Administration

This report deals with conducting a probabilistic study of the external tank attach ring (ETA) used as an interface between the external tank attach struts and the solid rocket booster. The ideas were to use probabilistic distributions for material, geometric, and load properties; to calculate probabilistic margins of safety; and then to compare results against the deterministic factors of safety that were used in the actual design process. The report describes how this was done and discusses some of the road blocks and data problems that were encountered during the study and provides some conclusions. A further refinement of this study is being considered for future work which would make more direct use of finite element analysis data coupled with Monte Carlo simulation. The basic conclusion herein indicates that the probabilistic margins of safety for the cases analyzed (by use of existing data) appear to support deterministic results and actually indicate higher reliabilities. Pizzano, Frank and Putcha, C. S. Marshall Space Flight Center...

• Format: Paperback
• Language: English
• ISBN: 1730727980
• ISBN13: 9781730727986
• Release Date: January 1
• Publisher: Independently Published
• Length: 68 Pages
• Weight: 0.40 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
