An Experimental Study of a Three-Dimensional Thrust Augmenting Ejector Using Laser Doppler Velocimetry

By National Aeronautics and Space Administration

Flow field measurements were obtained in a three-dimensional thrust augmenting ejector using laser Doppler velocimetry and hot wire anemometry. The primary nozzle, segmented into twelve slots of aspect ratio 3.0, was tested at a pressure ratio of 1.15. Results are presented on the mean velocity, turbulence intensity, and Reynolds stress progressions in the mixing chamber of the constant area ejector. The segmented nozzle was found to produce streamwise vortices that may increase the mixing efficiency of the ejector flow field. Compared to free jet results, the jet development is reduced by the presence of the ejector walls. The resulting thrust augmentation ratio of this ejector was also calculated to be 1.34. Storms, Bruce Lowell Unspecified Center EJECTORS; FLOW MEASUREMENT; LASER DOPPLER VELOCIMETERS; REYNOLDS STRESS; THREE DIMENSIONAL FLOW; THRUST AUGMENTATION; TURBULENCE EFFECTS; VORTICES; ASPECT RATIO; EXHAUST VELOCITY; HOT-WIRE ANEMOMETERS; NOZZLE DESIGN; PRESSURE RATIO; V/STOL AIRCRAFT...

• Format: Paperback
• Language: English
• ISBN: 1731249489
• ISBN13: 9781731249487
• Release Date: January 1
• Publisher: Independently Published
• Length: 132 Pages
• Weight: 0.71 lbs.
• Dimensions: 0.3" x 8.5" x 11.0"
