An electronically controlled automated security access gate

By Michael Ngumom Tyowuah

The control of access to a property or building that uses a gate is better done using electronic devices. The electronically controlled automated security access gate achieves this by using an RF transmitter-receiver pair. A microcontroller is programmed to decode a given sequence of charaters that is entered on a keypad and command a transmitter module to send out this code as signal at a given radio frequency. Upon reception of this RF signal by the receiver module, another microcontroller activates a driver circuitry to operate the gate by opening or closing it automatically. The codes for the microcontrollers were written in C language and were debugged and compiled using the KEIL Microvision 4 integrated development environment. The resultant Hex files were programmed into the memory of the microcontrollers with the aid of a universal programmer. Software simulation was carried out using the Proteus Virtual System Modelling (VSM) version 7.7. A scaled-down prototype of the system was built and tested, and found working okey. The electronically controlled automated security access gate can be useful in providing security for homes and organizations.

• Format: Paperback
• Language: English
• ISBN: 6200310432
• ISBN13: 9786200310439
• Release Date: September 2019
• Publisher: LAP Lambert Academic Publishing
• Length: 136 Pages
• Weight: 0.46 lbs.
• Dimensions: 0.3" x 6.0" x 9.0"
