Aerospace Threaded Fastener Strength in Combined Shear and Tension Loading

By National Aeronautics and Space Administration (NASA) and National Aeronautics and Space Administration

A test program was initiated by Marshall Space Flight Center and sponsored by the NASA Engineering and Safety Center to characterize the failure behavior of a typical high-strength aerospace threaded fastener under a range of shear to tension loading ratios for both a nut and an insert configuration where the shear plane passes through the body and threads, respectively. The testing was performed with a customized test fixture designed to test a bolt with a single shear plane at a discrete range of loading angles. The results provide data to compare against existing combined loading failure criteria and to quantify the bolt strength when the shear plane passes through the threads. Steeve, B. E. and Wingate, R. J. Marshall Space Flight Center NASA/TM-2012-217454, M-1330 TENSILE STRESS; LOADS (FORCES); FASTENERS; STRUCTURAL ENGINEERING; MECHANICAL PROPERTIES; SHEAR STRENGTH; AEROSPACE ENGINEERING; BOLTS; FAILURE MODES

• Format: Paperback
• Language: English
• ISBN: B08FKP8N82
• ISBN13: 9798672795058
• Release Date: January 1
• Publisher: Independently Published
• Length: 34 Pages
• Weight: 0.23 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
