A Nonlinear Modal Aeroelastic Solver for Fun3d

By: Nasa, National Aeronautics and Space Adm

A nonlinear structural solver has been implemented internally within the NASA FUN3D computational fluid dynamics code, allowing for some new aeroelastic capabilities. Using a modal representation of the structure, a set of differential or differential-algebraic equations are derived for general thin structures with geometric nonlinearities. ODEPACK and LAPACK routines are linked with FUN3D, and the nonlinear equations are solved at each CFD time step. The existing predictor-corrector method is retained, whereby the structural solution is updated after mesh deformation. The nonlinear solver is validated using a test case for a flexible aeroshell at transonic, supersonic, and hypersonic flow conditions. Agreement with linear theory is seen for the static aeroelastic solutions at relatively low dynamic pressures, but structural nonlinearities limit deformation amplitudes at high dynamic pressures. No flutter was found at any of the tested trajectory points, though LCO may be possible in the transonic regime. Goldman, Benjamin D. and Bartels, Robert E. and Biedron, Robert T. and Scott, Robert C. Langley Research Center NASA/TM-2016-219013, L-20621, NF1676L-22761

• Format: Paperback
• Language: English
• ISBN: 1794004017
• ISBN13: 9781794004016
• Release Date: January 1
• Publisher: Independently Published
• Length: 36 Pages
• Weight: 0.24 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
