A Historical Perspective of the Yf-12a Thermal Loads and Structures Program

By National Aeronautics and Space Administration

Around 1970, the Y-F-12A loads and structures efforts focused on numerous technological issues that needed defining with regard to aircraft that incorporate hot structures in the design. Laboratory structural heating test technology with infrared systems was largely created during this program. The program demonstrated the ability to duplicate the complex flight temperatures of an advanced supersonic airplane in a ground-based laboratory. The ability to heat and load an advanced operational aircraft in a laboratory at high temperatures and return it to flight status without adverse effects was demonstrated. The technology associated with measuring loads with strain gages on a hot structure was demonstrated with a thermal calibration concept. The results demonstrated that the thermal stresses were significant although the airplane was designed to reduce thermal stresses. Considerable modeling detail was required to predict the heat transfer and the corresponding structural characteristics. The overall YF-12A research effort was particularly productive, and a great deal of flight, laboratory, test and computational data were produced and cross-correlated. Jenkins, Jerald M. and Quinn, Robert D. Armstrong Flight Research Center RTOP 505-70-63...

• Format: Paperback
• Language: English
• ISBN: 1729053335
• ISBN13: 9781729053331
• Release Date: January 1
• Publisher: Independently Published
• Length: 40 Pages
• Weight: 0.26 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
