A General Multiblock Euler Code for Propulsion Integration. Volume 1: Theory Document

By: Nasa, National Aeronautics and Space Adm

A general multiblock Euler solver was developed for the analysis of flow fields over geometrically complex configurations either in free air or in a wind tunnel. In this approach, the external space around a complex configuration was divided into a number of topologically simple blocks, so that surface-fitted grids and an efficient flow solution algorithm could be easily applied in each block. The computational grid in each block is generated using a combination of algebraic and elliptic methods. A grid generation/flow solver interface program was developed to facilitate the establishment of block-to-block relations and the boundary conditions for each block. The flow solver utilizes a finite volume formulation and an explicit time stepping scheme to solve the Euler equations. A multiblock version of the multigrid method was developed to accelerate the convergence of the calculations. The generality of the method was demonstrated through the analysis of two complex configurations at various flow conditions. Results were compared to available test data. Two accompanying volumes, user manuals for the preparation of multi-block grids (vol. 2) and for the Euler flow solver (vol. 3), provide information on input data format and program execution. Chen, H. C. and Su, T. Y. and Kao, T. J. Unspecified Center NAS1-18703; RTOP 535-03-10-01...

• Format: Paperback
• Language: English
• ISBN: 1729361951
• ISBN13: 9781729361955
• Release Date: January 1
• Publisher: Independently Published
• Length: 48 Pages
• Weight: 0.30 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
