A Comparison of Three Methods for Measuring Distortion in Optical Windows

By: Nasa, National Aeronautics and Space Adm

It's important that imagery seen through large-area windows, such as those used on space vehicles, not be substantially distorted. Many approaches are described in the literature for measuring the distortion of an optical window, but most suffer from either poor resolution or processing difficulties. In this paper a new definition of distortion is presented, allowing accurate measurement using an optical interferometer. This new definition is shown to be equivalent to the definitions provided by the military and the standards organizations. In order to determine the advantages and disadvantages of this new approach, the distortion of an acrylic window is measured using three different methods: image comparison, moir interferometry, and phase-shifting interferometry. Youngquist, Robert C. and Nurge, Mark A. and Skow, Miles Kennedy Space Center NASA/TM-2015-218822, KSC-E-DAA-TN23489

• Format: Paperback
• Language: English
• ISBN: 1793988749
• ISBN13: 9781793988744
• Release Date: January 1
• Publisher: Independently Published
• Length: 42 Pages
• Weight: 0.27 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
