Winclr: A Computer Code for Heat Transfer and Clearance Calculation in a Compressor

By: Nasa, National Aeronautics and Space Adm

One of the concerns during inclement weather operation of aircraft in rain and hail storm conditions is the nature and extent of changes in compressor casing clearance. An increase in clearance affects efficiency while a decrease may cause blade rubbing with the casing. The change in clearance is the result of geometrical dimensional changes in the blades, the casing and the rotor due to heat transfer between those parts and the two-phase working fluid. The heat transfer interacts nonlinearly with the performance of the compressor, and, therefore, the determination of clearance changes necessitates a simultaneous determination of change in performance of the compressor. A computer code the WINCLR has been designed for the determination of casing clearance, that is operated interactively with the PURDU-WINCOF I code designed previously for determining the performance of a compressor. A detailed description of the WINCLR code is provided in a companion report. The current report provides details of the code with an illustrative example of application to the case of a multistage compressor. It is found in the example case that under given ingestion and operational conditions, it is possible for a compressor to undergo changes in performance in the front stages and rubbing in the back stages. Bose, T. K. and Murthy, S. N. B. AIRCRAFT SAFETY; APPLICATIONS PROGRAMS (COMPUTERS); CLEARANCES; HEAT TRANSFER; INGESTION (ENGINES); TURBOCOMPRESSORS; USER MANUALS (COMPUTER PROGRAMS); WEATHER; CASES (CONTAINERS); HAIL; PERFORMANCE PREDICTION; PROPULSION SYSTEM PERFORMANCE; RAIN; ROTORS; TURBOMACHINE BLADES; WORKING FLUIDS...

• Format: Paperback
• Language: English
• ISBN: 1790131715
• ISBN13: 9781790131716
• Release Date: January 1
• Publisher: Independently Published
• Length: 174 Pages
• Weight: 0.92 lbs.
• Dimensions: 0.4" x 8.5" x 11.0"
